The FDX-008WKI is a Fan Damper Control Module with Key Switch Input designed for compatible Mircom FleX-Net™ fire alarm control and annunciation systems. It provides a dedicated interface for operating and monitoring fan and damper functions associated with building fire safety systems.
The module features 7 three-position switches, allowing operators to select the required operating mode for configured fan or damper functions. Each switch is supported by 4 status LEDs, providing visual feedback for the associated equipment and helping operators identify operating conditions.
The FDX-008WKI also includes a key switch input for supported control configurations. It connects to the main fire alarm control panel or to the RAX-LCD Remote Annunciator when installed remotely.
For equipment control, the module uses the MIX-M500CH intelligent control relay module to operate fans or dampers. Two MIX-M501A monitor modules are used to provide the required status monitoring. These control and monitor modules should be ordered separately.
Switch Configuration:
-
7 three-position switches
-
4 status LEDs per switch
-
Integrated key switch input
Compatible Control and Monitoring Modules:
-
MIX-M500CH — fan or damper control
-
2 × MIX-M501A — equipment status monitoring
Connection Options:
-
Main fire alarm control panel
-
RAX-LCD when mounted remotely
Mounting Options:
-
With the Main Control Unit
-
In BB-1000 Series enclosures with a Remote Shared Display
-
In BB-5000 Series enclosures with a Remote Shared Display
The FDX-008WKI is suitable for fire alarm installations requiring centralized fan and damper operation, equipment status indication, and key-switch functionality within a compatible Mircom system.
