The IPS-2424DS is a Programmable Input Switches Module designed for compatible Mircom fire alarm control and annunciation systems. It provides a convenient interface for programmable system inputs, control functions, and status indication.
The IPS-2424DS is equipped with 24 selector switches, providing individual user-selectable control inputs. Each selector switch is associated with a 24 bi-colored LED indicators, capable of displaying red or amber status indication.
The module also includes 24 amber Select LEDs, providing dedicated visual indication for the selected switch or programmed function. This combination of selector switches and LED indicators allows system operators to monitor and control multiple programmable functions from a single module.
The IPS-2424DS can be mounted with the Main Control Unit or installed in compatible BB-1000 Series and BB-5000 Series enclosures when used with a Remote Shared Display.
Switch Configuration:
- 24 programmable selector switches
LED Indicators:
- 24 bi-colored LEDs
- Red or Amber indication
- 24 Amber Select LEDs
Mounting Options:
- Mounts with the Main Control Unit
- Compatible with BB-1000 Series Enclosures
- Compatible with BB-5000 Series Enclosures
- Supports configurations with a Remote Shared Display
The IPS-2424DS is suitable for fire alarm and annunciation applications requiring multiple programmable operator inputs and clear visual status indication in a compact module.
